SF2500EX23

SF2500EX23, Keypad Multiplexer, 7V, ±50 mA, Toshiba Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $300.00~600.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $300.00~600.00

PartNumber:: SF2500EX23

Brand:: Toshiba Semiconductor - Toshiba | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Linda's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-10

From Other Seller

Part Number:SF2500EX23
US $300.00 - 600.00
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
MOC3063

US $0.32 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SF2500EX23 is a keyboard multiplexer fabricated in sub.micron silicon CMOS Technology. The SF2500EX23 is designed to operate over wide operating voltage, with minimum power consumption and very low voltage drop from VCC. The device saves dozens of active and passive components and permits operating voltage far lower than the standard diode scheme. The applications of the SF2500EX23 include Cell Phones, PDAs, MP3 players.

Parametrics

SF2500EX23 absolute maximum ratings: (1)VCC, DC Supply Voltage: -0.5 to +7.0 V; (2)VI, DC Input Voltage: 0 ≤ VCC ≤ VCC +0.5 V; (3)VO, DC Output Voltage: -0.5 to + 7.0 V; (4)IIK, DC Input Diode Current VI < GND: ±50 mA; (5)IOK, DC Output Diode Current VO = GND: -50 mA; (6)IO, DC Output Sink Current: ± 50 mA; (7)ICC, DC Supply Current per Supply Pin: ± 100 mA; (8)IGND, DC Ground Current per Ground Pin: ± 100 mA; (9)TSTG, Storage Temperature Range: -65 to + 150℃; (10)TL, Lead Temperature, 1 mm from Case for 10 Seconds: 260℃; (11)TJ, Junction Temperature under bias: +150℃; (12)θJA, Thermal Resistance: 80℃/W; (13)PD, Power Dissipation in Still Air at 85℃: 800 mW; (14)MSL, Moisture Sensitivity: Level 1; (15)FR, Flammability Rating Oxygen Index: 28 to 34 UL 94 V.0 @ 0125 in; (16)VESD, ESD Test Voltage Human Body Model: > 3000V; Machine Model: > 300V.

Features

SF2500EX23 features: (1)Single Supply Operation; (2)Optimized for 1.8 V to 3.6 V VCC; (3)Tiny 3 x 3 mm QFN-16 Package; (4)Conforms to: JEDEC MO-220, Issue H, Variation VEED-6; (5)Very Low Voltage Drop; (6)Permits Operation Down to 1.65 V; (7)Near Zero Static Power; (8)ESD Protection: Human Body Model (HBM); > 3000 V, Machine Model (MM); >300 V; (9)Latchup Maximum Rating: 200 mA; (10)Pin-to-Pin Compatible with CM2500; (11)This is a Pb-Free Device.
