Product Summary

The R270CH12 is a distributed gate thyristor.

Parametrics

R270CH12 absolute maximum ratings: (1)VDRM/VRRM range: 200 to 800V; (2)TQ: 10 to 20μs; (3)Ths = 55℃, ITAV: 990A; (4)50% duty Sine wave, ITRM: 3000A; (5)Ccycle TSINK = 55℃ square wave, ITRM: 2000A/μsec.

Features

R270CH12 features: (1)REP/Non-rep, di/dt: 1000/1500A/μs; (2)TC = 25℃, ITRMS: 2000A; (3)TC = 25℃, IT: 1628A; (4)VR ≤ 60%, TJ = 125℃, ITSM: 11000A; (5)VR ≤ 10V, TJ = 125℃, ITSM: 12000A.

Diagrams

R270CH12 block diagram
