Product Summary
The SKT551/16E is a Thyristor module. The applications of the SKT551/16E include DC motor control, controlled rectifiers, AC controllers, recommended snubber network e.g. for VVRMS≤400V: R=33Ω/32W, C=0.47μF.
Parametrics
SKT551/16E absolute maximum ratings: (1)ITAV: 391A; (2)ID: 390A; (3)IRMS: 430A; (4)ITSM: 9000A; (5)I2T: 405000A2S; (6)VT: MAX.1.65V; (7)VT(TO): MAX.0.925V; (8)RT: MAX.0.45MΩ; (9)IDD;IRD: MAX.50MA.
Features
SKT551/16E features: (1)Hermetic metal case with ceramic insulator; (2)Capsule package for double sided cooling; (3)Shallow design with single sided cooling; (4)Off-state and reverse voltages up to 1800V; (5)Amplifying gate.
